Building an Internal MCP Server for Your Team's Tools

The ticket lookup service is a good first candidate because it is read-mostly, its failure modes are boring, and its data is already familiar to the team. Resist the urge to wrap the whole ticketing platform. Start with two or three tools:

Keep the server thin. It should translate a tool call into one upstream HTTP request, shape the response, and return. Business logic stays in the ticket service where it already lives and where it is already tested. The MCP layer adds discovery, schema validation and logging, nothing more.

A minimal server in Python with the widely used FastMCP pattern looks like this, modeled on the tool definition style shown in Elastic's writeup (Elastic Security Labs):

from fastmcp import FastMCP

mcp = FastMCP("tickets")

@mcp.tool()
def get_ticket(ticket_id: str) -> dict:
    """Fetch one support ticket by its id, e.g. TCK-1042."""
    return ticket_client.get(ticket_id)

if __name__ == "__main__":
    mcp.run()

That is enough to be discoverable. The hard part is not the decorator, it is the arguments.

Function calling and MCP are often confused. With function calling you embed tool schemas in each model API request and your application executes the call; with MCP a server owns both the schema and the execution, and clients discover tools at runtime (Prefect comparison). Because the schema is the contract, it deserves more care than the handler.

The protocol supports three server features: resources for context data, prompts for templated workflows, and tools for functions the model executes (specification). For a ticket lookup service, tools are the right primitive. A decision rule helps here:

• If the agent needs to decide when to call it, expose it as a tool.
• If the content is reference material the user reads, expose it as a resource.
• If it is a fixed multi-step instruction, expose it as a prompt.

Now the schema itself. A weak schema is the most common reason agents "fail" at MCP. Compare:

{
  "name": "search_tickets",
  "description": "Search support tickets.",
  "inputSchema": {
    "type": "object",
    "properties": {
      "status": { "type": "string" },
      "priority": { "type": "string" },
      "limit": { "type": "integer" }
    },
    "required": ["status"]
  }
}

with a version that constrains the model's choices:

{
  "name": "search_tickets",
  "description": "Search support tickets by status and optional priority. Returns at most `limit` summaries newest first.",
  "inputSchema": {
    "type": "object",
    "properties": {
      "status": {
        "type": "string",
        "enum": ["open", "pending", "closed"],
        "description": "Ticket lifecycle status. Use 'open' for anything unresolved unless the user says otherwise."
      },
      "priority": {
        "type": "string",
        "enum": ["low", "medium", "high", "critical"],
        "description": "Severity as set by the reporter. Omit to search all priorities."
      },
      "limit": {
        "type": "integer",
        "minimum": 1,
        "maximum": 50,
        "default": 10,
        "description": "Maximum tickets to return. Keep below 20 unless the user asks for more."
      }
    },
    "required": ["status"]
  }
}

Four rules follow from that example. Use enums for anything with a closed set of values, because a free string invites "Open", "OPEN" and "opened" in the same week. State required fields explicitly and keep the list short. Put defaults in the schema rather than the handler so the model knows what happens if it omits a field. And write descriptions as instructions to a competent colleague, including which value to prefer when the request is ambiguous.

One warning that is easy to miss: tool descriptions are an attack surface. Hidden instructions inside a tool description can make a model read files or exfiltrate data while the visible UI looks harmless, which is the core of tool poisoning attacks (Invariant Labs). Your own server should be reviewed like source code, and the tool inventory should be treated as reviewed artifacts, not as text an agent can rewrite at runtime.

The most common design mistake in internal MCP servers is inventing a new authentication path. If the ticket service already uses OAuth or your identity provider, forward the caller's credentials and let the existing service do the authorization check. Do not give the MCP server a shared service account with broad scopes, because every action will then look like it came from "mcp-bot" in the audit log.

Authorization in MCP follows OAuth 2.1 conventions rather than mandating one identity system, and is strongly recommended when the server touches user-specific data or when you need to audit who did what (authorization tutorial). The flow starts when an unauthenticated client hits the server and is answered with 401 Unauthorized and a pointer to protected resource metadata, after which the client discovers the authorization server, registers, and obtains a token (authorization tutorial).

There are two legitimate patterns, and picking one early saves rework:

Microsoft's guidance for MCP tool authentication draws the same line: key-based or managed identity for a shared identity where user context does not persist, and OAuth identity passthrough when each user's own permissions must carry through (Microsoft Foundry docs).

For a ticket system, passthrough is the right default. A support engineer asking an agent about a customer ticket should see exactly the tickets their own account can see, not every ticket in the company. Concretely, your server does three things:

1. Accept the bearer token from the MCP request and keep it in request scope, never in a module-level variable.
2. Attach it to the upstream call to the ticket service as the caller's token.
3. Map a 401 or 403 from upstream into a tool error that says "not permitted" rather than retrying or falling back.

Bearer tokens travel with requests, so keep them out of logs. Redact the Authorization header at the logging layer, and if you cache, scope the cache key by user and keep the time-to-live short.

If your host runs servers locally over standard input and output, the transport story is simpler: local servers can take credentials from the environment instead of a full OAuth flow, because the process runs on the user's own machine (authorization tutorial). That is fine for a developer laptop and wrong for a shared deployment, so decide which one you are shipping before you write the auth code.

An unlogged MCP server is a black box the moment an agent starts behaving oddly. You will want to answer three questions: what did the agent send, what did we return, and how long did it take. Log all three for every tools/call, plus the tools/list requests, because a mismatched tool inventory is itself a failure mode.

A practical log line carries a correlation id, the tool name, a hash of the arguments or the arguments with fields redacted, the upstream status, the response size and the duration. Something like:

{
  "correlation_id": "01J8QK3C7R",
  "event": "tool_call",
  "tool": "get_ticket",
  "args": {"ticket_id": "TCK-1042"},
  "upstream_status": 200,
  "duration_ms": 84,
  "response_bytes": 3120,
  "principal": "user:jdoe"
}

Three habits make these logs useful. First, generate the correlation id on entry if the client did not supply one, and include it in the error text returned to the agent, so a user reporting a bad answer gives you a searchable handle. Second, record the principal from the forwarded token, which is only possible if you chose passthrough auth. Third, treat the logs as an audit trail with the same retention rules as the ticket system, since they show which agent read which customer data.

Datadog's guidance on monitoring MCP servers frames this as a broader observability question rather than a logging question: which tools exist, who invokes them, with what inputs, and whether the responses look sane (Datadog MCP monitoring). Even a single log stream covers a surprising amount of that if it is consistent.

Test with a client you control, not with an agent. The protocol ships development tools for exactly this, including the MCP Inspector for exercising servers (architecture overview). Anthropic's MCP course builds the same habit, listing the inspector as the way to test and debug servers you have written (Anthropic Academy course).

A checklist that catches most problems before a real agent does:

The injection probe deserves a sentence of explanation. Tool responses go into the model's context, and the trust gap between reviewing a tool description at connect time and trusting every response at runtime is the root cause of MCP tool poisoning (OWASP). You cannot fully solve that inside your server, but you can constrain output to a fixed JSON shape and reject anything that does not match, which catches the obvious cases (OWASP). For a ticket service, returning a typed object rather than a free-text blob is both better for the model and safer.

Run this checklist against the inspector and against one real client before announcing the server. Then run it again after any schema change, because a widening change (a new enum value, a new optional parameter) can silently change what agents do.

Not every internal API deserves a server. If you are writing deterministic automation that runs the same way every time, call the API directly; MCP is for agents and people working in natural language, and most teams end up running both (Mitiga comparison). The practical test is the shape of the request, not the size of the system.

Three signals say "wrap it as an MCP server":

• More than one agent or client needs the same data, so a single integration pays for itself.
• The questions are open-ended ("what did the customer report about login last week?") and you cannot predict the call sequence.
• You need a controlled, audited surface where every access is logged and authorized per user.

Two signals say "do not bother":

• Exactly one automation needs the data and you know the exact call.
• The data is a static document that fits in a resource, or a single fixed workflow that fits in a prompt.

Once the first server exists, the second is much cheaper, because the auth, logging and test harness are already there. That compounding is the real argument for standardizing on MCP internally rather than writing a bespoke tool wrapper per agent.
