Structured Output for Approval: A Schema Reviewers Read

The short answer is six required blocks. Here is the field level detail, with the failure each field prevents.

Two design rules make the difference between a schema reviewers read and one they scroll past. First, every block is required and validated at submission time, so an agent that cannot produce evidence cannot file the request at all. Second, free text is allowed only in reason.summary and rollback.plan, both capped in length. Everything else is an identifier, an enum, a timestamp or a typed value. That is what makes the payload renderable as a card instead of a wall of text, and it is what lets you diff two requests mechanically.

The action block should carry a JSON Schema of the parameter set alongside the actual values. Schema plus values means the reviewer can see that amount is a decimal with two places and currently equals 480.00, not that the agent "wants to refund a customer."

{
  "action": {
    "call_id": "call_01J8Z9K3",
    "tool": "billing.refund",
    "params_schema_ref": "billing.refund@v2",
    "params": [
      {"name": "invoice_id", "type": "string", "value": "INV-88213"},
      {"name": "amount", "type": "decimal(10,2)", "value": "480.00"},
      {"name": "currency", "type": "string", "value": "USD"},
      {"name": "reason_code", "type": "enum", "value": "DUPLICATE_CHARGE"},
      {"name": "notify_customer", "type": "boolean", "value": true}
    ]
  }
}

The params_schema_ref matters more than it looks. It pins the review to the exact contract the tool validates against, so if the tool later gains a batch parameter, old approvals stay tied to the old contract. It also gives you a cheap check: reject any payload whose declared types do not match the tool's registered schema before a human ever sees it.

A worked comparison shows why scale belongs next to the parameters. Suppose two queued refunds both read as approved-in-principle under a policy that allows refunds. The first is 480.00 to one invoice with no downstream notification. The second, built from the same schema, carries amount 480.00, a batch list of 340 invoice IDs, and notify_customer true. The policy says yes to both; only the payload tells the reviewer that the second touches 340 customers in one call. That gap is exactly what blast-radius gates exist to close, because a rule permitting refunds says nothing about how many of them can stack up before someone looks the blast-radius gate analysis.

The evidence block is where most approval designs quietly fail. An agent writes "per the customer email, they were double charged," and the reviewer has no way to check that without opening a separate search tool. The fix is to require a list of typed, timestamped references rather than prose the structured approval payload walkthrough.

{
  "evidence": {
    "items": [
      {"source_type": "ticket", "id": "ZD-44120", "field": "body",
       "retrieved_at": "2026-02-11T09:14:02Z", "excerpt": "charged twice in February"},
      {"source_type": "ledger_query", "query_id": "q_7731",
       "retrieved_at": "2026-02-11T09:14:40Z", "row_count": 2},
      {"source_type": "policy_doc", "id": "FIN-REFUND-POLICY", "section": "4.2",
       "retrieved_at": "2026-02-10T22:00:00Z"}
    ],
    "missing": ["customer_confirmation_of_second_charge"]
  }
}

Two fields do heavy lifting. The retrieved_at timestamp bounds staleness: a policy document read two weeks ago may since have changed. And the missing array lets an agent declare what it could not verify, which is far more useful to a reviewer than a confident sentence hiding the gap. A reviewer scanning for risk reads the missing array first. If the agent's plan depends on a fact that is not in the evidence list, the request is not ready to submit.

This is also the field that keeps the human decision meaningful. The wider human-in-the-loop literature is blunt that a human who cannot see the basis of a decision is not really in the loop, and the reliance on explainability to make oversight useful is well documented across the review of the field the Springer survey of human-in-the-loop machine learning. Evidence references are the cheapest form of explainability an agent can produce, because they cost one lookup each and no extra generation.

The risk block should encode a decision you have already made elsewhere, not an opinion the model produces at submission time. A four-tier classification is the common pattern in production practice: reads pass freely, reversible production changes need one approver, destructive or irreversible changes need two, and security-sensitive changes are refused outright at the gate the nofire runtime enforcement guide. A parallel treatment for AI SRE work uses the same four tiers and pairs reversible production changes with a single on-call approver and destructive changes with two approvals including the service owner the production access analysis.

Encode that as an enum plus the facts the tier was computed from:

Put a warning on the last row. Confidence from a language model measures token likelihood, not factual accuracy, and teams have reported incorrect agent actions carrying high confidence scores, which is why confidence cannot be the only routing signal the HITL patterns field report. Use it to color the card, not to skip the gate.

The tier table is also how you prevent confirmation fatigue. Requiring a human to approve reads and reversible internal writes trains reviewers to click through without reading, and the point of a risk tier is to reserve interruptions for the small set of actions where the answer could be no the SaaS approval workflow guide. Fewer, better requests is a security property, not a convenience.

Rollback is one sentence and three facts: the undo operation, whether it has been tested, and who owns it if it needs a human at 3 a.m.

{
  "rollback": {
    "plan": "issue compensating reversal for INV-88213 amount 480.00 USD",
    "operation": "billing.reverse_refund",
    "tested": true,
    "owner": "billing-platform",
    "time_to_undo_minutes": 5
  },
  "dry_run": {
    "status": "passed",
    "ran_at": "2026-02-11T09:15:12Z",
    "result_url": "https://ops.internal/dryruns/01J8Z9K3",
    "diff_recorded": true
  }
}

If the dry run failed or was skipped, the request should not be submittable at the tier that auto-approves on a clean dry run. If tested is false on an irreversible action, the payload should demand a second approver. These are schema-level rules, enforced before a human is interrupted, and they remove the reviewer's need to interrogate the agent for obvious gaps.

A dry-run link is worth more than a paragraph about what would happen. It is the same principle as an approval gate placing evidence in front of the approver before a production change runs the production access analysis. The reviewer opens the diff, sees the affected rows, and closes the tab. That is a decision in seconds, not a research project.

Where do you run the dry run when the target system has no sandbox? Two options that scale: snapshot the target records into a scratch store and execute the tool against it, or compile the action into a reversible diff (a JSON patch, a SQL transaction that ends in rollback) and attach that. Either way, the artifact is a URL, and the URL goes in the payload.

Schema design and screen design are the same project. If the blocks exist, the card writes itself. A layout that reviewers can scan in under a minute:

1. Header: tool name, tier badge, one-sentence reason, request timestamp.
2. Action table: parameter, type, value, with any value outside a policy bound highlighted.
3. Evidence list: source, ID, retrieved time, excerpt, plus the missing array at the top if non-empty.
4. Risk strip: records affected, systems touched, reversible yes or no, confidence as a neutral number.
5. Rollback line: plan, tested flag, owner, minutes to undo.
6. Dry run: status badge and link.
7. Decision: approve, edit then approve, reject, request more evidence, each recorded against call_id.

Review queues work better when they are a shared inbox with a clear evaluation question attached, rather than a spreadsheet of transcripts, and the same discipline applies here: one request per ticket, a fixed question, and a recorded judgment that later becomes training data for better triage the MLflow review queue writeup. The four decision buttons matter too. Approve and reject alone force a reviewer to choose between a bad action and a stalled workflow; edit-then-approve lets them fix a wrong parameter without sending the agent back to plan from scratch, and that option is explicitly configurable in the LangChain interrupt model the LangChain HITL docs.

If you are building this surface as an internal tool and would rather describe it than hand-roll it, Quanta can take the description and build the review console alongside your schema: describe the tool you need.

Validate the payload before it reaches a human. A JSON Schema check catches missing blocks and wrong types, and a second pass runs your policy checks: irreversible actions missing a rollback owner, batch parameters exceeding the tier's record bound, evidence items older than the allowed staleness window. Anything that fails is returned to the agent as a validation error, not shown to a reviewer.

Then log the decisions. Every approval, edit and rejection should be stored with the payload that produced it, because those pairs are the most valuable dataset you will generate: real agent requests with human verdicts attached, which is exactly the raw material for tuning the triage that decides which requests need a person at all the MLflow review queue writeup. Treat schema versions as contracts. Adding a required field is a breaking change for every agent that files requests, so version the schema (schema_version in the root) and keep old versions valid until their queued requests drain.

Two metrics tell you whether the schema is working. Time-to-decision on tier 2 and tier 3 requests tells you whether the card is readable; if median time creeps up, a block is probably hiding the fact reviewers need. Edit rate tells you whether the agent's parameters are trustworthy; a high edit rate on one tool means that tool's argument generation needs work, not that reviewers need more training.
