Writing Tool Schemas That Survive Model Upgrades

Free text is where model upgrades show up first. A schema with an untyped date string invites "next Friday (I think?)"; a schema with format: date and a documented example invites 2026-11-20. Every field in your schema should answer three questions: what type is it, what values are legal, and is it required.

Use these rules in order:

• Enums for anything closed. Status, priority, region, channel. An enum removes a whole class of drift, because a model cannot invent URGENT when only low, medium, high and critical are listed.
• Typed scalars with formats. integer with minimum and maximum for limits, string with format: date-time for timestamps.
• Explicit required. List required fields; leave optional fields genuinely optional and give them a default. A model that must guess between required and optional will sometimes invent values.
• additionalProperties: false where your executor rejects unknown keys, so the failure is visible at validation time instead of deep in a handler (structured outputs guide).

The money row is worth dwelling on. amount_cents as an integer plus an explicit currency enum removes float rounding and unit ambiguity in one move; compare that with a single "amount": "25.00 USD" string that every model will format differently.

Descriptions tell a model what a field means. Examples tell it what a value looks like. Put one realistic example per non-obvious field, and keep it identical to what your production data actually contains. If your tickets have IDs like TKT-48291, show TKT-48291, not abc123.

{
  "name": "search_tickets",
  "description": "Search support tickets by status and priority. Returns at most `limit` tickets, newest first.",
  "parameters": {
    "type": "object",
    "properties": {
      "status": {
        "type": "string",
        "enum": ["open", "closed", "pending"],
        "description": "Lifecycle state of the ticket. Example: open"
      },
      "priority": {
        "type": "string",
        "enum": ["low", "medium", "high", "critical"],
        "description": "Support tier. Example: critical"
      },
      "limit": {
        "type": "integer",
        "minimum": 1,
        "maximum": 100,
        "default": 10,
        "description": "Maximum rows returned. Example: 25"
      }
    },
    "required": ["status"],
    "additionalProperties": false
  }
}

Two habits matter here. First, the description says what the tool returns, not just what it does; a model plans multi-step calls better when it knows the shape of the result. Second, examples live in the schema, never in a vendor-specific prompt. When you switch models mid-project, the schema travels intact and nobody has to rewrite "Remember, dates are ISO" prose.

A worked example shows the cost of skipping this. Say you run 40,000 tool calls a day and 3 percent fail argument validation. At 1,200 failures a day and a five-minute average manual fix, that is 100 engineer-hours a day of cleanup. Adding enums and format checks typically collapses the bulk of those failures into one move: a model can still guess wrong, but it now guesses among legal values.

A schema is a request for a well formed call. It is not a security control. MCP's own specification treats tool descriptions and annotations as untrusted unless they come from a trusted server, and requires explicit user consent before invoking a tool (MCP specification). Build your validation with that in mind.

The main risk is tool poisoning, where hidden instructions inside a tool description steer the model toward reading files or leaking data; Invariant Labs showed a benign-looking add tool whose docstring told the model to read SSH keys and pass them as a parameter (Invariant Labs). A related variant hides instructions in tool responses rather than descriptions, which the model then treats as trusted context (OWASP MCP Tool Poisoning). Elastic documents related patterns including rug-pull redefinitions, where a tool changes behavior after it has been approved (Elastic Security Labs).

Three defenses belong in your schema layer, not your prompt:

1. Constrain output shape. Require structured responses with a fixed schema and reject anything that does not match. OWASP lists schema validation as the first practical catch for injected instructions in free text.
2. Separate privilege. Read-only tools and write tools should not share an agent context with external servers, so a poisoned response cannot chain into a privileged call.
3. Enforce limits server-side. Check authorization and rate limits in the executor, not in the system prompt, which injected instructions can override.

def execute(tool, args):
    errs = validate(tool.input_schema, args)   # types, enums, required
    if errs:
        return {"error": "invalid_arguments", "details": errs}
    if not acl.allows(current_user, tool.name, args):
        return {"error": "forbidden"}
    return handlers[tool.name](**args)

This loop is the same for function calling and MCP. Validate, authorize, execute, log. Observability tools that trace MCP and agent sessions help you attribute failures to a schema change, a model change or a bad call (Datadog MCP monitoring).

The MCP specification itself is versioned by date (YYYY-MM-DD) and only bumps the version when a change breaks compatibility; deprecated features stay in place for at least twelve months, or ninety days under an expedited-removal exception (MCP versioning). Copy that pattern for your tools. Date your schema revisions, keep additive changes additive, and never silently rename a field that a model may be calling with today.

The checklist that keeps a schema swap boring:

Keep a machine-readable changelog next to the schema. A caller that fails validation should get the schema version and a pointer to the changelog in the error, so the next model that trips on a narrowed enum produces one actionable message instead of a mystery. Resources and prompts follow the same idea and are separately versioned in the spec (MCP resources, MCP prompts), so a tool, a resource and a prompt that ship together carry the same revision.

The only way to know a schema survives a model upgrade is a golden set of cases run against every model you plan to use. Build it once, run it in CI, and compare.

A practical harness has four parts:

• Cases: 50 to 200 prompts per tool, including ambiguous ones ("highest priority stuff from yesterday"), edge values (limit 0, limit 1000) and adversarial text that looks like injected instructions.
• Checks: schema validity rate, exact argument match against an expected object, tool-selection accuracy when several tools are exposed, and a safety check that no privileged tool was called without approval.
• Baseline: store results per model and schema version, so an upgrade shows a diff instead of a vibe.
• Gate: fail the build if validity or selection accuracy drops more than a set threshold against the current production model.

When you move to a new model, whether through a provider API or through a single gateway such as Quanta Inference that fronts text and other model types with an OpenAI-compatible interface, the harness runs unchanged because the schema is outside the vendor format. The same holds if your experts or coding agents are the caller: keep the schema fixed and the model swappable.

Two operational rules finish the job. First, keep model-specific hints (system prompt nudges, temperature, reasoning settings) in adapter code that lives alongside each model config, never inside the JSON schema; that way the adapter can be deleted when the model is retired and the contract stays. Second, canary the switch: route 5 percent of traffic to the new model, watch validation-failure rate and tool-selection accuracy for a day, then widen. If the new model produces worse arguments, the cause is almost always a vague description or a missing enum, and that fix improves every model at once.
