Exit Codes and Output Contracts for Agent Tools

The practical rule is to define your own tiny scheme in the range above the shell's reserved values, document it in --help and in the tool's README, and treat it as API. A working set for agent-called tools looks like this.

This is close to the scheme published in a widely read guide on writing CLIs for agents, which uses 0 for success, 1 for general failure, 2 for usage error, 3 for not found, 4 for permission denied and 5 for conflict in Writing CLI Tools That AI Agents Actually Want to Use. The additions here are the transient and partial classes, which matter for batch operations and network calls.

Two decision rules follow from the table. First, reserve 1 for "unclassified bug in the tool" so it never means anything a caller could act on. Second, keep the set closed: if a new failure does not fit an existing class, you almost always want it to become an input error or a permission error rather than a new code, because every new code costs the agent a branch it must learn.

An agent that receives 5 can decide to skip creation and move to the next step; an agent that receives 1 for everything has to parse stderr to guess what happened, and it will sometimes guess wrong per the same guide. That sentence is the whole argument for a closed table.

The contract has a second half: what goes where. Stdout is the API. Stderr is the human channel. Progress bars, spinners, warnings, retry notices and deprecation chatter belong on stderr so they never corrupt a pipe.

A production example of this discipline comes from the OpenStatus CLI rebuild, which routes every output decision through a terminal check: spinners show only when stderr is a TTY, color respects NO_COLOR, and JSON mode strips formatting entirely per Building a CLI That Works for Humans and Machines. The same post reports a --debug flag that logs HTTP method and duration to stderr specifically so it never corrupts piped output.

A short check you can run against any tool before you hand it to an agent:

# stdout should parse as JSON with nothing else mixed in
mytool list --json 2>/dev/null | python3 -c 'import json,sys; json.load(sys.stdin)'

# stderr should still carry the diagnostics
mytool list --json 2>&1 >/dev/null | head -5

# exit code should survive the pipe
mytool list --json >/dev/null; echo "exit=$?"

If the first command fails, an agent will fail too, because it parses on the assumption that stdout is one clean document. If the third prints anything other than the documented code, the branch logic downstream is already broken.

Two more output rules earn their keep. Prefer flat keys over deep nesting (pod_status rather than pod.status.phase), and keep types stable: if a duration is a number in one command, do not return a prose string like "3 days" in another per the CLI guide. When output is incremental, emit one JSON object per line so the agent can process it as a stream.

Agents check exit codes and parse output to decide what to do next, so a tool that returns 0 on failure breaks every workflow that depends on it per the same guide. Treat a wrong exit code as a data-integrity bug, not an ergonomics issue.

An error message for an agent is closer to a repair instruction than a log line. It needs three parts: what failed, which input is implicated, and what to do next. The OpenStatus team rewrote raw RPC codes into exactly that shape: monitor 999 not found. Run 'openstatus monitors list' to see available monitors, and authentication failures tell the caller to check the token environment variable and verify with a whoami command per their engineering post.

The same post shows the pattern for missing arguments in non-interactive mode: the tool lists precisely the flags that are absent (missing required flags: --title, --status, --message, --page-id), which is concrete enough for a model to retry with the right values per the same post. Their design also handles the two-audience problem with a "wizard fallback": if required flags are missing and stdin is a terminal, a human gets an interactive form; otherwise the tool errors with the exact missing flags.

Write your messages to that standard with a checklist.

One more discipline: never put success text on stderr and then exit 0, and never print an error to stdout and then exit 0. The pipe and the code must agree.

Agents retry. Networks fail. A command gets interrupted halfway. If your create command fails on the second run because the resource already exists, the agent must write special-case retry logic for your tool alone per the CLI guide. Make creation idempotent and return 0 with the existing object, or return 5 with the existing ID so the caller can decide.

For batch work, the exit code alone cannot carry enough information. Exit 78 plus a per-item report on stdout is the usable combination: the agent reads which items failed and retries only those. Without the report the agent must re-run the whole batch, which is how duplicate side effects get created.

Retries also need a cap. Long-horizon agent runs degrade as tasks stretch: one production analysis found success rates start falling after roughly 35 minutes of human-equivalent work, and doubling task duration roughly quadruples the failure rate rather than doubling it per a survey of long-horizon planning research. A tool that keeps returning "transient" invites the agent into exactly that failure mode. Return the transient class a bounded number of times, then switch to a code that means escalate.

That research also notes that after 25 to 30 tool calls even large context windows show coherence problems, with agents re-executing steps they already finished per the same survey. Idempotent commands and precise "already exists" codes are the cheapest defense against re-execution damage.

You are not only choosing exit codes; you are choosing a transport. The three common ways to hand a capability to an agent have different contract surfaces.

The sandbox column is worth understanding because a good sandbox already implements the contract you want. Production sandboxes standardize an execute interface for shell commands that returns stdout, stderr, exit codes and truncation notices, with filesystem access through explicit tools rather than unrestricted access per an overview of agent code execution. If your CLI mirrors that return shape, it behaves the same whether the agent runs it directly or inside a sandbox.

On the CLI versus MCP tradeoff, the reported experience is that tool schemas in MCP sit in the prompt before the tool is used, and JSON-RPC framing adds per-call overhead; one author measured roughly 40 percent lower token use after replacing a simple MCP server with a CLI per the CLI guide. The same guide says MCP still wins when you expose dozens of tools behind one server, need stateful sessions, or want protocol-level composition. Either way, the exit code and output rules carry over.

An agent-facing document is also a contract problem. A spec-driven workflow that has the agent write requirements, then a plan, then an ordered task list before any code is written gives both the human and the agent checkpoints to review per JetBrains' guide to spec-driven coding. Apply the same sequence to your tool: write the interface spec (codes, channels, message shape) as a file, review it, then implement against it.

The evidence standard matters too. A published audit of agent "done" claims found no passing test run behind 65 to 69 percent of them, depending on how strictly they were counted per a definition-of-done guide for coding agents. The guide's remedy is a checklist enforced by a hook or CI job that runs after the agent stops and records each command with its exit code, with the passing run required to happen after the agent's last edit per the same guide. Notice what that checklist asks for: exit codes. Your tool's contract and the agent's evidence trail are the same artifact.

Minimum test suite for a tool you expose to agents:

1. One test per documented exit code, asserting the exact code and that stdout stays empty or schema-valid.
2. A pipe test proving --json stdout parses with logging enabled.
3. An idempotency test running create twice and asserting the documented second-run behavior.
4. A partial-failure test on a batch with one bad item, asserting exit 78 and a per-item report.
5. A message test asserting every error names an argument or a next command.

If you use coding agents to build these tools, the contract file doubles as instructions they can follow. A skill library lets you install that discipline into the agent rather than restating it each session; Quanta Skills is one place to start, and the same skills underpin every Quanta expert that reads your context and returns finished deliverables.

Suppose an agent calls report export --since 2026-01-01 --format csv. Here is one concrete run and how the numbers decide the contract.

• The job needs 4,200 rows from an API that pages at 200 rows per call, so it makes 21 upstream requests.
• Request 17 returns HTTP 429 after 12 seconds. The tool retries twice with backoff and succeeds; the run stays on the success path and exits 0.
• Rows 3,880 to 3,900 fail schema validation (a changed currency field). The tool does not exit 0. It writes the good rows to stdout, lists the 21 rejected row IDs in a stderr report and on stdout in --json, and exits 78.
• The agent reads 78, sees that 99.5 percent of rows are valid, writes the good rows to disk, and retries only the rejected IDs rather than re-running 21 upstream requests.
• Had the same run failed the first three retries on request 17, the tool would have exited 75 with upstream timeout after 3 attempts (36s). Retry later or lower --page-size. The agent backs off instead of looping.

The arithmetic is the point. A catchall exit 1 would have forced the agent to re-run the whole export, repeat 21 network calls, and possibly duplicate the 4,179 good rows on disk. One extra documented code saved the batch.
